Key Telephony Features
• Place / Cancel outgoing call
• Answer / Decline incoming call
• Redial (last 10 calls)
• Caller ID on display
• Numeric / alphanumeric dialing
• DTMF navigation
• Mute Volume control
• Message Waiting Indication (MWI)
• Speakerphone (half duplex)
• 10 speed dial keys
• Call pick up
• Address book
• 12 selected ringing melodies
• Do no disturb
• Auto answer mode
• Hands free dialing
• Blind transfer, Attended transfer
• Conferencing
Large scale deployment
The SIPXPERT 160 phone offers key features and capabilities for service providers to provide customized services to their subscribers. The SIPXPERT 160 phone can be remotely provisioned and configured. This saves providers the time, cost and hassle of managing, pre-configuring and reconfiguring customer premise equipment.
Support for PPPoE, DHCP and static IP
Point to Point Protocol over Ethernet (PPPoE) is a standard for connecting
multiple units through the same router or CPE device. By using PPPoE, service
providers are able to provide access control and billing functionality
in a manner similar to dial-up services, in addition to providing type
of service on a per user, rather than a per site basis. In many areas of
the world PPPoE is a requirement for deploying devices in IP networks.
The SIPXPERT 160 phone supports DHCP, which makes it easier to deploy and maintain
IP telephony networks.
TOP
VoIP Protocol Stack:
SIPv2 - Session Initiation Protocol Version 2 (RFC3261)
• Power-on auto-registration
• Re-registration with SIP Proxy Server (Configurable interval setting)
• SIP over UDP
SDP stack (RFC2327)
SIP authentication (HTTP Digest with MD5)
NAT traversal for private networks with STUN (RFC3489)
H.323 and MGCP Firmware available on demand
Vendor certified with Asterisk Open Source IPBX in SIP
Phone User Services:
Content sensitive soft keys
Five programmable feature buttons
Fixed function keys
Numeric / alphanumeric dialing
Redial key
10 speed dial keys
Mute function
Speakerphone (group listening)
Message Waiting Indication (MWI)
Caller number and ID display
Date and Time display
Call timer display
Call status display
Voice Features:
Audio Codec support
• G.711 (A-law and Mu-law),
• G.723.1
• G.726 (16/24/32/48)
• G.729 AB
Exchange of Codec capability
Dynamic Payload
Adjustable Audio Frames per Packet
DTMF In-band and Out-of-Band (RFC2833)
Tone Generation
• Dial Tone
• Ring Back Tone
• Busy Tone
• Network Busy Tone
Adaptive Jitter Buffer
Packet Loss Concealment
VAD - Voice Activity Detection
CNG - Comfort Nice Generation
Attenuation / Gain Adjustments
Dynamic volume control
Acoustic Echo Cancellation (G.165, G.167)
TOP
Data Networking:
MAC Address (IEEE 802.3)
Ethernet (10BaseT)
IPv4 - Internet protocol Version 4 (RFC791)
ARP - Address Resolution Protocol (RFC826)
DHCP Client - Dynamic Host Control Protocol (RFC2131)
ICMP - Internet Control Message Protocol (RFC792)
TCP - Transmission Control Protocol (RFC793)
UDP - User Datagram Protocol (RFC768)
RTP - Real Time Protocol (RFC1889) (RFC1890)
PPPoE - Point to Point Protocol
Type of Service - TOS (RFC791)
DiffServ (RFC2475)
Security:
Password Protected Administration
Admin and User Access Authority
HTTP Digest - Encrypted Authentication via MD5
Provisioning, Administration and Maintenance:
Web Browser Administration and Configuration via Integrated Web Server
• IP (static or DHCP)
• STUN (address, port, port max/min, refresh interval)
• SIP (display name, username, password, device URL, proxy
URL, registrar URL, register interval)
• Audio (preferred codec, force codec, min TX packet time, volume)
• Upgrading (with image from disk)
Automated Provisioning & Upgrade
Local configuration with keypad/LCD Display
Physical Interfaces:
Two RJ-45 Port - Ethernet 10Bt (IEEE 802.3)
One RJ-11 Port - For Handset
TOP
Indicators:
LAN (Activity LED and Link) LED
Phone Status LED (Login OK)
Speaker LED
Mechanical & Physical:
Housing: Anti-fire ABS plastic material, in black color
Dimension: 170 * 190 * 46 (mm)
LCD Display: 2x16 lines
Wall mounting and Stand kit support
5V DC, 600 mA . power adapter
Keypad: 28 keys
Dialing keypad: 0-9,#,*
Dedicated function keys:
Speaker, Mute, Redial, Hold(*), Transfer /
Conference (*) and Message (*), Menus (and for Web-configuration),Volume
control, Enter, Cancel and Programmable feature buttons
Operating Temperature: 0 0 C to 45 0 C (32F to 1 F)
Storage (or non-operating) Temperature: -10 0 C to 60 0 C ( F to
F)
Humidity: operating: 20% to 80% non-condensing
Storage (or non-operating):10% to 90% non-condensing
