EdgeWater Products

Critical solution products for service providers and enterprises looking for better monitor/manage VoIP quality.

The EdgeMarc suite of Converged Networking Appliances offer small to large enterprises reduced operational and capital expenses of up to 90% while improving call quality, security, and simplifying the user experience. They are an all-in-one solution that contain all of the features needed to deliver business class VoIP services. All EdgeMarc products are Plug & Dial ready, allowing service providers and enterprises to install hosted VoIP service in minutes, not hours.

The Edge View VoIP Support System is a VoIP troubleshooting and monitoring pltaform that allows service providers and enterprises to deliver the best possible support at the lowest cost. Several operators have seen a marked improvement in installation/configuration time, call resolution as well as a reduction in hard operational costs. The EdgeView system scales with the Service Provider or Enterprise and is available in a redundant, high availability carrier-grade form factor.

The EdgeView Reports is an advanced yet easy-to-use reporting tool that provides valuable VoIP performance information to network planners, operators, product managers, executive management teams and end-users. The EdgeView Reports server works in conjunction with the EdgeView VoIP support System and EdgeMarc routers to provide unprecedented visibility into the performance of today’s converged networks.

The EdgeProtect platform is designed to protect managed VoIP service providers from network-based attacks and perform NAT/FW traversal for "road warriors" to extend the reach of VoIP services. It combines topology hiding, dynamic session admission control and stateful packet inspection to secure critical VoIP and data infrastructure components such as VoIP softswitches, gateways and media servers. The EdgeProtect platform is available in two form factors: 5300 Series - Provides 2 x 10/100/1000 Mbps Ethernet interfaces, and support for up to 500 simultaneous VoIP calls. 6400 Series - Carrier grade system providing 2 X 10/100/1000 Mbps interfaces, redundant AC or DC power and support for up to 1000 simultaneous VoIP calls.

Contact ABP to learn more about these devices.

Feature List
Technical Specifications
Downloads

Feature List

EdgeMarc Appliances

Several form factors, scale

VoIP survivability

SIP, H.323 support

Automated phone configuration

Call quality monitoring, MOS prediction

Raw quality statistics (jitter, latency, etc,)

NAT/PAT

VoIP and Video over IP prioritization

Traffic shaping, Diffserv, Policing, Call Admission Control (CAC)

Stateful packet inspection firewall

VoIP protocol aware NAT/firewall

SNMP, telnet, SSH, HTTP, HTTPS, Radius

Syslog external and local reporting

PING, traceroute, TCPdump utilities

Plug & Dial

Integrated FXS/FXO

Expandable up to 4, T1’s using MLPPP or MLPPP/FR

Integrated IAD/gateway for analog and PSTN connectivity

Integrated WiFi

EdgeView VoIP System

Automated plug & dial setup of IP phones, EdgeMarc and EdgeConnect devices

Advanced knowledgebase

Configuration/setup of CPE including EdgeMarc, EdgeConnect, and IP phones

MOS (mean opinion score) statistics capture - continuous and historical

Proactive notification of poor call quality using SNMP traps or email

Call signaling capture and analysis for advanced troubleshooting (call-ladders)

Secure transfer of User Agent authentication credentials

Local EdgeMarc storage of configuration files

Works with existing NMS infrastructure

Image management and group upgrades for multiple nodes

High availability with optional dual redundant, hot swappable AC or DC power supplies

GUI-based interface

Tiered administration privileges and multiple user accounts

TOP

Technical Specifications

EdgeMarc SOHO Appliances Models 200E, 200EW, 200A, 200AW

WAN Ports - 1X10/100 Mbps Ethernet only models 200E and 200EW

ADSL Ports: 1 x ADSL, ADSL2, ADSL 2+ only models 200A and 200AW

LAN Ports - 4X10/100 Mbps Ethernet

Serial Ports - 1XRS-232 (DB9)

Dimensions - 1.7" (H) x 6.3" (W) x 10.5" (D)
Weight - 2 lbs

Power - 12V, 3.0 A

Operating Temperature - 5°C - 40°C ambient

Humidity: 20%-80% non-condensing

Regulatory - UL, CE, FCC, Part 68, FCC part 15, Industry Canada CB

Ports: 2 FXS, 1 FXO.

WiFi: 802.11 a/b/g only models 200EW and 200AW

VLANs: 16

EdgeMarc SMB Appliances Models 4500, 4500T4, 4508T4, 4508T4W, 4563T4W, 4508E

WAN Ports - 1X10/100 Mbps Ethernet

LAN Ports - 4X10/100 Mbps Ethernet

Serial Ports - 1 Female DB9

Dimensions - 1.7" (H) x 10" (W) x 7" (D)
Weight - 2 lbs

Power - 12V, 3.0 A

Operating Temperature - 5°C - 40°C ambient

Humidity: 20%-80% non-condensing

Regulatory - UL, CE, FCC, Part 68, FCC part 15, Industry Canada CB

Ports:

WiFi: 802.11 a/b/g only models 4508T4W and 4563T4W

USB Ports: 2

VLANs: 16

EdgeView VoIP Support SystemModel 5300

WAN Ports - 1X10/100 Mbps Ethernet

LAN Ports - 1X10/100 Mbps Ethernet

Aux Ports - 1X10/100 Mbps Ethernet

Serial Ports - 1XRS-232 (DB9)

Dimensions - 1.68" (H) x 16.88" (W) x 14" (D)
Weight - 13 lbs

Power - 100/240v VAC, auto-selecting, 50 to 60 Hz

Regulatory - FCC part 15, VCCI Class A, MIC, C-tick, ICES-003, RoHS

EdgeView VoIP Support System & EdgeView Reports Server Model 6400

WAN Ports - 1X10/100 Mbps Ethernet

LAN Ports - 1X10/100 Mbps Ethernet

Aux Ports - 1X10/100 Mbps Ethernet

Serial Ports - 1XRS-232 (DB9)

Dimensions - 3.45" (H) x 17.14" (W) x 20" (D)”
Weight - 45 lbs

Power- 2x600W AC or DC Power Supplies

Regulatory - Safety: RoHS, UL 60950, CSA 60950, IEC 950, TUV/GS EN60950

Emissions: FCC ClassA, CISPR 22 Class A, EN 55022 Class A, VCCI
