Aastra SIP-DECT ™

Building Blocks for Mobility

Employing the latest DECT 6.0 technology, the SIP-DECT Solution from Aastra offers superior levels of interference-free performance, security and reliability in a cordless SIP telephone system.

This scalable, enterprise grade, mobility solution allows users to take the features and voice quality of their desk telephone with them throughout their office environment or related branch offices serviced by the same Corporate network.

DECT technology virtually eliminates issues of dropped calls, interference, security and range by employing IP DECT access points that seamlessly “handoff” calls and enable roaming. This system is ideal for any single or multi-location business, retail or institutional setting that requires mobile employees to be available to take or receive calls at any time.

Aastra Cordless SIP deployment using DECT has the following advantages:

• DECT 6.0 standard in the 1.920-1.930 GHz
• Users are provisioned as SIP extensions
• Fully feature enterprise class Handset
• Indoor & Outdoor access points (RFPs)
• Reliable, high quality, secure voice access
• Seamless handover between access points
• Automatic roaming & registration of handsets
• Digital quality - automatic best channel selection
• DECT Authentication/Encryption
• No PBX required in the remote offices/locations
• Network size depends on the IP-infrastructure only
• Up to 512 handsets can be deployed using up to 256 IP access points

Contact ABP to learn more about these Aastra™ cordless phones.

Features
Technical Specifications
Downloads

Features

Power:

Call Forward: always, busy, no answer (phone side)

Call logs: dialed, missed, received

Personal directory 100 entries

Redial list

Call Transfer: blind, consultation

Call waiting

MWI

Caller ID with name

DND

Call Hold with visual indication, reminder tones

Missed call indicator

Speed dial quick call key assignment

Call blocking / filtering

30 ring tones

Single and Continuous Ring

Loud Speaker (hands-free mode)

Speaker / Earpiece Volume Adjustment

Ringer Volume Adjustment

Vibrate Mode

Keyboard lock

Alarm / Reminder

Microphone Mute

Auto-answer

Country specific tones

Languages English, French, German, Italian, Spanish, Dutch, Portuguese

Site Survey mode with automated test call/answer modes

TOP

Access Points:

Synchronization via air interface

GAP compatible

Connection handover according to GAP standard

Authentication/Encryption of base and handset

Operating states monitoring with 3 LEDs

Connection via Ethernet 10/100 BaseT

IPv4, Power over LAN according to IEEE 802.3af

Platform for the Open Mobility Manager

8 simultaneous Voice and up to 12

Signaling Channels

Endpoint for media streams

Packet handling via RTP/RTCP

Network Boot, SW-Download / Update

DHCP

Codec G.711, G.723, G.729AB

Support of QoS via DiffServ and ToS-Flag

Jitter compensation

Echo Cancellation

Voice Activity Detection with comfort noise

Central configuration with the WEB - configurator of the “OpenMobility” Manager

Central system log book

Central cluster administration

3 LEDs for signalization of operation status

Alternative wiring from below (Cable channel) or from above (suspended ceiling)

TOP

Technical Specifications

DECT 142 HANDSET

Display (LCD)
4 lines of 16 characters, 3 line text, 1 line soft keys (upper and lower case, 96 x 60 pixels) Illuminated display and keypad.
Status indicators-Ringer off, signal strength, on/off hook, alarm, battery life, envelope,
key lock
Time Display
User Name & Number
Network Subscription
Display Contrast Adjustment

Physical
Integrated Antenna
Size (approx.) 146mm x 53mm x 28mm
Weight 138 grams (inc. batteries)
2.5mm headset jack

Powering
Batteries: 3 AAA 750 mAh NiMH
Input: 100-120V 60 Hz 100mA
Output: 7.5V DC 150mA
Lower Battery Warning
Silent Charging
Desk Charger Power Adapter
Up to 12 hours talk time, 120 hours standby
5-6 hours recharge time

Performance
Frequency: 1.92 - 1.93 GHz
300,000 sq.ft. coverage area (open space)
Coverage Warning
GAP Compatible (EN 300 444)
Site Survey Mode
Auto call generation/answer mode

TOP

Downloads

Aastra SIP-DECT Spec Sheet 0.21MB
